Turn off the machine and release pressure
Wear protective gear (gloves, safety glasses)
Loosen the pressure sensor with a 17mm wrench
Check the seal and replace if necessary
Tip: If the sensor is damaged, order a replacement here.
Connect the calibration pump
Gradually increase pressure
Check readings on the digital manometer
Calibration device connected
Pressure values checked
Sensor readings adjusted
Reinsert the sensor and tighten securely
Gradually restore system pressure
Calibration was successfully completed!
Start the machine and verify sensor readings
Inspect all connections for leaks
